Cat 6 U/UTP Lan Cable – Unshielded Bulk Ethernet Cable for Enterprise Networks

Model: IS9021

Product Overview

The IS9021 is a commercial-grade Cat6 U/UTP (Unshielded Twisted Pairs) bulk LAN cable, designed for high-performance indoor horizontal cabling and local area network (LAN) applications. Featuring a non-metallic unshielded structure, it delivers superior flexibility, occupies less routing space and cuts down installation time, while fully complying with strict Category 6 gigabit transmission standards.

Manufactured in accordance with international telecommunication specifications, this cable boasts stable performance and cost advantages. It is an ideal choice for global network distributors, commercial system integrators and structured cabling installers.

Key Technical Features

• Gigabit Networking Performance: Supports a maximum bandwidth of 250MHz and transmission speed up to 1000Mbps. It works stably with 5GBASE-T protocols over standard 90-meter horizontal channels with ample performance margin.
• High-Purity OFC Conductor: Adopts solid 23AWG 99.99% oxygen-free copper conductors, effectively reducing signal attenuation and DC resistance. Fully compatible with standard PoE/PoE+ applications for excellent transmission efficiency.
• Central HDPE Cross Separator: Built-in high-density polyethylene cross skeleton physically separates four twisted pairs. It maintains stable cable structure during installation, greatly reduces Near-End Crosstalk (NEXT) and optimizes signal performance.
• Slim & Flexible Design: With an outer diameter of only 6.10 mm, the cable features outstanding flexibility. It is suitable for narrow conduits, patch panels and high-density cable trays in various commercial buildings.
• Flame-Retardant Sheath Options: Standard PVC sheath for general indoor networking; optional LSZH (Low Smoke Zero Halogen) sheath to meet local building fire safety and smoke emission regulations.

Technical Specifications

Typical Structure Parameters

Mechanical & Electrical Performance

Installation & Environmental Guidelines

• Operating Temperature: $-10℃ \sim +60℃$
• Installation Temperature: $0℃ \sim +40℃$
• Minimum Bending Radius (During Laying/Pulling): ≥ 8 × OD
• Pulling Tension: Short-term ≤ 110 N; Long-term ≤ 20 N

Compliance & Industry Standards

Our products strictly conform to mainstream global telecommunication cable standards, supporting participation in international infrastructure and commercial bidding projects.

• ANSI/TIA 568.2-D
• ISO/IEC 11801
• YD/T1019
• UL444

B2B Service, OEM & Logistics Support

• OEM/ODM Customization: Custom jacket printing, brand logo, jacket color and sheath material available to meet diverse project demands.
• Export-Grade Packaging: Wound on wooden reels and packed with heavy-duty corrugated cartons. Custom pallet packaging for sea freight is also provided to avoid damage during transit.
• Flexible Trade Terms: Supports FOB, CIF, EXW, CFR and other international trade terms to ensure reliable delivery for bulk orders.

Technical SEO Optimization Elements

Meta Information Settings

• Meta Title: 23AWG OFC Cat6 U/UTP Lan Cable Bulk | Factory Direct Supply IS9021
• Meta Description: Wholesale IS9021 Cat6 U/UTP unshielded LAN cable. Equipped with 23AWG oxygen-free copper and PE cross separator, ideal for indoor enterprise horizontal structured cabling. Feel free to inquire about tiered wholesale & OEM prices.
• Target Keywords: Cat6 U/UTP Lan Cable, Unshielded Bulk Ethernet Cable, Commercial Cat6 Network Cable, Wholesale Unshielded Lan Cable, 23AWG Unshielded Network Cable, Indoor Structured Cabling Supplier

Request a Commercial Quotation / RFQ

We are looking for long-term cooperative partners for bulk supply of high-performance and cost-effective unshielded network cables for inventory and commercial projects. We provide tiered wholesale prices, complete quality inspection reports and one-stop OEM services.

To receive an accurate quotation within 12 hours, please kindly provide the following details in your inquiry:

1. Total order quantity (Total meters, reels/cartons or full container load)
2. Sheath material requirement (PVC or LSZH according to local indoor safety standards)
3. Customization demands (Jacket color, printing content, etc.)
4. Destination port (For accurate CIF freight calculation)
