Factory Bulk Cat 6A U/UTP 23AWG Oxygen-Free Copper Lan Cable – 10Gbps 500MHz Unshielded Network Cable

• Product Model: IS9031
• Brand: Support Private Label / OEM / ODM Customization

■ Product Overview

Owire Model IS9031 is a highly efficient, high-performance Cat 6A U/UTP Lan Cable meticulously engineered for indoor horizontal work area wiring and general indoor LAN wiring setups.

By eliminating bulky external shielding layers, this lightweight design optimizes installation flexibility while relying on a precision-designed internal cross PE skeleton structure to maintain optimal pair separation. Utilizing premium 23AWG pure oxygen-free copper conductors, it reliably delivers a massive 500MHz bandwidth and ultra-stable 10Gbps data transmission speeds over a distance of up to 90 meters. Fully compliant with international structured cabling standards (ANSI/TIA 568.2-D, ISO/IEC 11801), this cable offers rich margin support for system links alongside cost-effective, high-speed network reliability.

■ Key Features & B2B Advantages

• 10Gbps High-Speed Routing & 500MHz BandwidthFormally rated to provide a typical application rate of 10Gbps at a horizontal channel distance of 90 meters. It seamlessly handles high-frequency, data-heavy workloads across corporate servers, enterprise cloud computing networks, and modern office infrastructures.
• Optimized Unshielded (U/UTP) Design for Swift InstallationThe unshielded architecture drastically cuts down overall cable weight, thickness, and stiffness. This makes routing through narrow conduit pathways, tight drop ceilings, and standard office drywall significantly quicker, cutting labor costs on massive commercial projects.
• Premium 23AWG Pure Oxygen-Free Copper (OFC)Built with high-quality solid copper as the transmission conductor to guarantee reliable electrical performance. It ensures exceptionally low electrical DC resistance ($73.2\ \Omega/\text{km}$), proving highly efficient for steady Power over Ethernet (PoE/PoE+/PoE++) applications compared to lower-grade alternatives.
• Precision Center Cross PE Skeleton SeparationAdopts a center cross PE skeleton designed to separate the 4 separate wire pairs cleanly. This rigid internal geometry dramatically reduces internal near-end crosstalk (NEXT) and structural deformation, ensuring long-term signal integrity during high-tension pull-throughs.
• Tailored Jacket Material Options (PVC / LSZH)Available with standard heavy-duty PVC outer sheaths for default internal applications, or Low Smoke Zero Halogen (LSZH) compounds to strictly comply with municipal building safety laws, public tenders, and high-density office fire codes.

■ Technical Specifications

■ B2B Customization & Wholesale Logistics Packaging

• Standard & Custom Packing: Packaged on strong, highly secure 305m (1000ft) easy-pull wooden reels or customizable master cartons. Full palletization, specialized container loading configurations, and personalized length divisions are available upon commercial request.
• OEM/ODM Cable Marking: We offer custom high-precision laser printing on the cable jacket. You can specify your proprietary brand name, regional regulatory compliance logos, custom part numbers, and sequential meter markings to match local tender documents.

✉️ Contact a Global Network Cable Expert Today for Free Samples!

Are you a B2B distributor stocking inventory or a system integrator bidding on an upcoming indoor enterprise commercial layout? Contact us right now to receive our wholesale tier price matrix, Fluke testing report proofs, and the official technical PDF datasheet for the Model IS9031 Cat 6A U/UTP cable.
